Fiber Laser Cutting Machine – RD-CFH3015B
Specially used for cutting 0.5-6mm carbon steel, 0.5-5mm stainless steel, 0.5-2mm aluminum, 0.5-1mm brass and other metal material, The effect of cutting speed and cutting section of superior performance..
Features
One whole set design, it can be assembled quickly, cover small area, save space.
Double driver systems with precision gear and rack. Rapid positioning.
The exchange workbench, automatic blanking, save operation time and improve production efficiency.
| Laser Power | 500W/800W |
|---|---|
| Laser Source |
IPG (Germany) nLight (USA) Max/Recus (Chinese) |
| Laser Wavelength | 1064nm |
| Working Size | 1500×3000 mm |
| Max. Positioning | 60m/min |
| Max. Accelerated | 0.5G |
| X/Y-axis positioning accuracy | +- 0.5mm |
| X/Y-axis repeating positioning accuracy | +- 0.3mm |
| Working Voltage | 380V 50HZ |
| Total Power | <10KW |
| Machine Weight | 5500K.G. |
| Machine Outer Dimensions | 8100x2600x1655 mm |
| Transmission | Previse pinion and rack, dual-drive transmitting |
